Air Cooled Chiller Unit With Screw Compressor

Air Cooled Chiller Unit With Screw CompressorModel:RO-330ASParameters 1、Cooling Capacity (kw/h) :325-373 2、Power Supply:3phase-380/415-50/60Hz 3、Input Power（KW）:112 4、Energy Control Range:100%-75%-50%-25%-0% 5、Compressor :Screw Semi-hermetic Power（KW）:90 Start Way:Y-Time 6、Refrigerant:R22 Charge（KG）:73 Flow Control:Thermostatic Expansion Valve 7、Evaporator:Shell and Tubes Cold Water Flow（m3/h）:60 Water Resistance（Kpa）:53 Water Pipe Size（mm）:100 8、EER:3.1 9、Condenser:Fan Coil 10、Temperature Control Range（°C）:5-35 11、Discharge Pressure（PA）:15-18 12、Discharge Temperature（°C）:80-100 13、Ambient Working Temperature（°C）:40 14、Max Running Current（A）:177 15、Unit Net Weight（KG）:3350 16、Unit Running Weight（KG）:3500 17、Dimension L×W×H（mm）:4000*2260*2570 Disposition 1、Compressor: Hanbell 2、TaiwanBangPuelectronicboardofmicrocomputer 3、LGExchangethecontactor,LGHeatRelay 4、TaiwanRichOilpressuregauge 5、Capillarythrottleunit 6、AlcoDryingfilter 7、Fengshenmagneticvalve 8、Fancoiltypeevaporator 9、FancoiltypecondenserProtectiveDevice 1、Fanoverloadprotector 2、High/lowvoltageprotector 3、Anti-freezeprotector 4、ElectronicDelayedProtector。
